KCL – Large Air Cooled Condensers

1 to 14 Fan Models, in Single and double width, with Vertical or Horizontal Air Discharge for limitless installation and application opportunities.

KCM – Medium Air Cooled Condensers
July 21, 2016
Large Direct Drive Fluid Cooler
KFL – Large Direct Drive Fluid Coolers
July 21, 2016
Show all

CONTACT A PRODUCT SPECIALIST TODAY:

[email protected]
1-844-893-3222 ext. 526

Overview
Refrigeration or Air Conditioning Duty, 1 to 14 Fan Model, Single width and double width models available, Vertical or Horizontal Air Discharge
Features/Options

Certification:
Features:
    • Compatible with Low GWP Refrigerants
    • Internally Enhanced Tube
    • Narrow width condenser design to suit shipment in containers.
    • THERMOSPAN™ coil design feature eliminates tube failure on tube sheets.
    • Enhanced Copper Tube, (3/8 O.D. on 1-6 Fan, 1/2 O.D. on 8-14 Fan), Aluminum Fin Condenser Coils
    • Standard 850 RPM quiet low speed dual voltage (230/460) fan motors with male electrical plug, moisture slinger, and rainshield for complete weather protection.
    • Swept wing fan for quiet operation and optimal efficiency
    • Rugged heavy-gauge galvanized steel rail motor mounts / support.
    • All fan sections individually baffled with full height partitions, and clean-out panels.
    • Complete selection of electrical fan cycling and speed control options.
    • Heavy-gauge galvanized steel cabinet construction assembled with zinc plated huck bolts supported on heavy-duty legs.
    • 2-Fan wide units have two equal circuits
    • Terminal block
    • Single entering electrical service
    • Control circuit voltage – 230 V
    • Control circuit transformer where applicable
Available Options:

Optional features (Factory Mounted)

      • Multiple refrigeration circuits
      • Fan Cycling – Ambient thermostat / fan row with contactors
      • Fan Cycling – Pressure control / fan row with contactors
      • Fan Cycling – in pairs with ambient thermostat
      • Variable speed motor with controller for header fan motors
      • Individual fan motor fusing
      • Individual ambient thermostat or pressure control
      • Non-fused disconnect
      • Horizontal air discharge configuration
      • Variable Speed EC Motor which provides optimum efficiency and sound levels
      • Adjustable flooded head pressure control
      • Extended leg kits (36” or 48”) with cross bracing for extra rigidity
      • Optional 550 ultra low and 1140 RPM high speed motors available.
      • Adjustable Flooded HPC is factory mounted if a base frame with mounted receiver is ordered
      • Optional fin materials
      • Optional coil coating

Specifications

Application:
  • Refrigeration or Air Conditioning Duty
  • 1 to 14 Fan Models
  • Single width and double width models available
  • Vertical or Horizontal Air Discharge
  • Compatible with a wide variety of refrigerants: R404A, R22, R507, R407C, R-407A, R-134A, R-410A
Capacity:
  • Sizes range from 12 to 230 nominal tons (based on 25° TD, R404A)
Electrical:
  • 208-230/3/60
  • 460/3/60
  • 575/3/60
  • 200-220/3/50
  • 380/3/50
